ME550 CR80 DATA MATRIX

General

The ME550 CR80 DATA MATRIX is a portable metal tag embosser to mark alphanumeric characters and 2D DATA MATRIX barcodes on CR80 tag sizes (85,6 mm x 54 mm / 3.37” x 2.13”) ideal for permanent marking of aluminum and stainless steel tags. The 2D DATA MATRIX barcode has the great advantage of containing a high volume of data on limited space. With a 10% increase in production speed, a completely renewed design and new features, the ME550 CR80 DATA MATRIX is an advanced solution that can be integrated into any existing factory or office network.

7” color touchscreen display with high resolution
The ME550 CR80 DATA MATRIX is equipped with a built-in 7 "WVGA LCD touchscreen display with simple and easy to use icon and buttons. The user can access and manage machine functions through a multi-level menu in an easy and intuitive way.
IoT (Internet of Things) remote access and management
- Web services: The machine set-up and operations can be entirely managed remotely via the web or through the use of VNC (Virtual Networking Computing) client, using a personal computer or other devices connected to the Customer’s network.
- Data transfer: Data import/export and the machine updating can be managed from any device connected to the embosser via Ethernet by using the FTP protocol (file transfer protocol).
USB (type A, type B), Ethernet and WiFi
The ME550 CR80 DATA MATRIX can be connected to a personal computer, to load data and start production, or to another device, such as keyboard, barcode reader or other if needed.

The ME550 CR80 DATA MATRIX is a completely self-contained tag marking machine, and is ideal for component and production line identification and traceability applications. Designed to operate in harsh industrial environments and easy to transport.

For additional transportation needs CIM offers CASE 500 a heavy-duty transport case, with integrated wheels and a pull-up handle which makes movement of the case easy. Download the brochure >>
